Authorized Goldfinger distributor 6 configurations

Goldfinger 32-Inch Infrared, PCAP, and Non-Touch Line

32-inch family. Buy 405064 without lamps or 405068 with lamps. Infrared rows are 205064 and 205068.

From $495

Price shown is the price you pay — no quote form.



  • 3-year manufacturer warranty from Goldfinger
  • 30-day returns — no questions asked
  • Out-of-warranty repair at $65 labor plus parts
  • Replacement parts in stock
  • Mon–Fri, 9am–5pm ET · (877) 922-6707

About the Goldfinger 32-Inch Infrared, PCAP, and Non-Touch Line

The 32-inch Goldfinger page mixes touch methods, so the item number is the order. Priced rows: 405064 PCAP, no bezel, standard flange, no lamps; 405068 PCAP, extruded, with lamps; 205064 infrared, no bezel, standard flange; 205068 infrared, no bezel, extruded, with lamps. Two buy buttons point at 405064 and 405068. 405058 is non-touch and call-for-price. 405072 is an upgrade kit (monitor, bracket, parts, and cables), also call-for-price, and it is not a bare panel.

The size table lists a 32-inch diagonal, PCAP multi-touch, 16:9, active area 698.4 by 392.85 mm, 1920 by 1080, refresh 60 Hz to 75 Hz, video ports HDMI, DVI-D, and VGA, viewing plus or minus 89 degrees, 8-bit color at 16.7 million, 400 nits, response 8 ms, contrast typical 1200:1, 24V DC, draw 42.6 W typical and 47.3 W maximum, chassis 758.70 by 453.25 by 54 mm, weight 23.5 lb (10.66 kg), and 0 C to +50 C. Frames on the sheet are standard flange and extruded. Lamps are optional, which is the split between 405064 and 405068.

Infrared items 205064 and 205068 are real rows even though the measurement block is titled PCAP. Non-touch 405058 is a third path. Warranty text is three-year standard, manufacturer warranty, Goldfinger Inc. A 32-inch unit outside that warranty is $65 labor plus parts. The upgrade kit 405072 should be ordered with the cabinet item number in the note, because the kit is more than the glass. Keep the infrared and PCAP prices on their own rows when you write the quote.

Configurations and prices

Goldfinger 32-Inch Infrared, PCAP, and Non-Touch Line configurations, item numbers and prices
Item #Configuration FramePrice Order
20506432" IR, No Bezel, Std FlangeStandard panel$670Order by phone
20506832" IR, No Bezel, Extruded, LED LightsStandard panel$770Order by phone
40506432" PCAP, No Bezel, Std FlangeExtruded frame, LED halo$495 $670 Buy now
40506832" PCAP, Extruded, LED LightsExtruded frame, LED halo$575 $770 Buy now
40505832" Non-TouchExtruded frame, LED haloCall for pricingGet a price
40507232" Upgrade Kit - Monitor, Bracket, Misc. Parts and CablesExtruded frame, LED haloCall for pricingGet a price

Buy Now opens the same item on our store, BillAcceptors.us, at the same price. Configurations without a listed price are stocked to order — call (877) 922-6707. Every new unit is covered by our 30-day, no-questions-asked return policy.

Specifications

Goldfinger 32-Inch Infrared, PCAP, and Non-Touch Line manufacturer specifications
Display Size32" Diagonal
Touch TechnologyPCAP (Projected Capacitive) – Multi-Touch
Aspect Ratio16:9
Active Area698.4 mm (H) x 392.85 mm (V)
Max Resolution1920 (H) x 1080 (V)
Video Refresh Rate60 Hz - 75 Hz
Video I/O PortsHDMI; DVI-D; VGA
Viewing AngleHorizontal: ±89°; Vertical: ±89°
Number of Colors8-bit depth; 16.7M colors
Brightness Rating400 nits
Response Time8ms
Contrast RatioTyp: 1200:1; Max: 900:1
Power24V DC
Power ConsumptionTyp: 42.6W; Max: 47.3W
Monitor Dimensions758.70 mm x 453.25 mm x 54 mm
Weight23.5 lbs / 10.66 kg
Operating Temperature0°C - +50°C
Warranty3 Year Standard (manufacturer warranty, Goldfinger Inc)
Frame OptionsStandard Flange, Extruded
Optional FeaturesLED Lights

Measured for 405080 (Touch w/ LED), 405068 (Touch w/o LED), 405064 (Standard, touch, w/o LED), 405086 (No touch, w/o LED). Other item numbers in this family share the panel but vary by frame, flange, bezel and touch type — see the configuration table above.

Source: Goldfinger PCAP Products Brochure (Goldfinger LLC, (c) 2024). Published by Goldfinger, reproduced here by E & D Trading, Inc. as an authorized Goldfinger distributor.

Spec sheets and downloads

Goldfinger’s own documentation, provided for reference. Need a dimension that is not on the sheet? Call (877) 922-6707.

Already own a Goldfinger 32-Inch Infrared, PCAP, and Non-Touch Line?

We repair Goldfinger monitors that are out of warranty at $65 labor plus parts, and stock the replacement parts. Call (877) 922-6707.
